Barium Titanate
BaTiO3

Crystal properties

Crystal Structure

Tetragonal(4m) 13oC<T<132oC

Cell parameter

a=3.99Å, c=4.04Å, (at 26 oC)

Melting Point

1891 oK

Density.

6.06 g/cm3 (at 26 oC)

Specific Heat

0.527 J/g·k (300°K)

Thermal conductivity

6 W/m·k (300°K)

Thermal expansion (10-6k-1)

15.7∥?a 6.2∥?c

Dielectric constant(εer)

εea=3000 εec=800

Hardness (Mohs)

4.5

Growth Method

TSSG (Top Seeded Solution Growth)

Index of Refraction

515 nm

633 nm

800 nm

no

2.4912

2.4160

2.3681

ne

2.4247

2.3630

2.3235

Transmission wavelength

0.43 - 6.30 um

Electro Optic Coefficients.

rT13 = 8+ / -2 pm/V



rT33 = 105-/+10 pm/V



rT42 = 1300+ / -100 pm/V

Reflectivity of SPPC ( at 0 deg. cut )

50-70 % (Ce: BaTiO3) for lamda = 515 nm



40-60 % (PureBaTiO3) for lamda = 515 nm



50-80 % (Ce: BaTiO3) for lamda = 633 nm



40-60 % (PureBaTiO3) for lamda = 633 nm

Two-wave mixing coupling constant.

10-40 cm-1

Absorption loss
Lamda:
a :


515 nm
0.285cm-1


633 nm
0.108cm-1


800 nm
0.033cm-1

Wavelength range for photo refractive effect

Undoped BTO

for visible





Ce: BTO

480-780nm





Rh: BTO

720-1060nm



Specifications

Standard Size

10x10, 10x5,

10x3, 5x5 mm



Thickness

0.5mm, 1.0mm





Polishing

one or two side polished



Bulk

5 x 5 x 5 mm

4 x 4 x 4 mm

3 x 3 x 3 mm,



0° or 45° cut, 2 - 6 faces polished

Orientation

<100>, <110>, <001>, <111>

Orientation accuracy

± 0.5°
